Quansheng Taiko Kong TK-11 has generated a lot of excitement in the ham radio community, thanks to its promising features and robust design.

User-Friendly Interface: The Taiko Kong TK-11 features a 1.44-inch ice blue display, offering clear readability even in low light. Combined with an intuitive keypad layout, this makes the handheld easy to operate, whether you’re new to ham radio or a seasoned operator. The user interface is designed to ensure that navigating through settings and frequencies is straightforward and hassle-free.

Quad-Band Operation: This handheld supports four key frequency bands right out of the box: 10m, 6m, 2m, and 70cm. Whether you’re working local, regional, or global communications, the TK-11 offers flexible coverage to suit various ham radio needs.

Long Battery Life: Powered by a 2500mAh battery, the Taiko Kong TK-11 ensures extended field operation. This makes it an ideal companion for long-duration ham radio activities, whether you’re operating in the great outdoors or during an emergency scenario where power outlets may be scarce.

General Specifications

• Channel Capacity: 999 channels, ensuring ample storage for all your favorite frequencies.
• NOAA Weather Channels: 10 channels to keep you updated on weather conditions.
• FM Radio Presets: 32 preset stations for easy access to your favorite broadcasts.
• Voltage: 7.4V for reliable performance.
• Battery: 3000mAh, providing hours of operation on a single charge.
• Dimensions: 126mm x 58mm x 34.5mm, a compact size that’s easy to carry without sacrificing screen space.
• Weight: 301g, making it lightweight yet sturdy enough for demanding use.
• Screen: 1.44-inch ice blue display for clear viewing.
• Keypad: A front-facing 19-key keypad with 2 dedicated PTT keys and 2 programmable shortcut keys for convenient access to frequently used functions.
• Speaker: 16-ohm 1W speaker for clear audio output, even in noisy environments. 🔊
• Operating Temperature: -20°C to 60°C, making it suitable for extreme weather conditions.
• Charging: Supports both Base Charger and Type-C USB charging, adding convenience to your daily charging routine.

Transmitting Specifications

• Transmission Bands: 25-29.8MHz, 50-54MHz, and 136-174MHz, allowing for versatile communication across different ranges.
• Output Power: 10W, providing a strong signal for long-range communication.
• Modulation Modes: Capable of 16KOF3E (25kHz) modulation, ensuring clarity in your transmissions.
• Emission Current: ≤2.5A for efficient power consumption.
• Adjacent Channel Power: 70dB (25kHz) and 60dB (12.5kHz), minimizing interference and ensuring quality communication.

Reception Specifications

• Frequency Range: Covers an impressive 0.15-1160MHz, making it a versatile receiver for a variety of signals.
• FM Sensitivity: -121dBm for high-quality reception.
• WFM Sensitivity: -108dBm for receiving wideband FM signals.
• Audio Power: ≥0.5W for powerful audio output, ensuring you hear every important message clearly.
• Audio Distortion: ≤10%, maintaining clear audio fidelity.
